Domotika

Kit includes two pulleys, with fasteners, wire cable, tensioning brackets and cable clips. Screws, hardware and hex key for fastening included.

Available up to 200 cm (100+100).
Applicable when the counterframe is installed.
Combination with the soft closing kit is recommended.

Pneumatic system-invisible from the outside-that automatically closes the sliding door once it has been opened; allows both keeping the door fully open and adjusting the closing speed.

Kit includes a pneumatic piston, support with pulley, drag bracket, magnet and steel cable. Hardware included.

Can be applied with the counterframe installed, thanks to the pull-out track.
It reduces the passage clearance by 30 mm.
Available for doors up to 40 kg weight and 100 cm opening.

Use of the system on doors subject to specified regulations should be verified by the customer in accordance with national laws.

The 150 kg trolley kit consists of 2 ambidextrous self-centering trolleys, each equipped with 4 coated ball bearings, self-centering and interlocking drawbar, brackets for attaching the door panel, adjustable bumper rubber grommet, and variable-hardness trolley stop at rail closure. The kit also includes hardware, dowels and bolts for fastening.
Suitable for wooden door panels.

Kit includes a 40, 50 or 80 kg shock absorber and attachment system. Screws and hardware included.
All soft closing kits can be installed inside the track, making the system integral with the door panel and invisible from the outside, thanks to the special sliding bracket.

Can be applied with the counterframe installed, thanks to the removable rail.
Applicable only to wooden door panels.

The upper element (crosspiece) fits doors opening up to 100 cm.
The vertical element (pillar) fits doors up to 210 cm in height.
Finish to be painted.
Other sizes are available, for feasibility contact the company.

Accessory that makes it possible to obtain a double counterframe by joining two single ones, suitable for both plasterboard and plaster versions.
To join two individual counterframes, it is necessary to cut the rails by 50 mm.

The integrated motorization kit is the kit invisible from the outside that allows the movement of door panels to be automated.
Includes: a 24V gearmotor with stand, 230Vac/24Vdc board-transformer, belt with panel fastening system, idler pulley with belt tensioning system.

Can be installed with the counterframe already in place, reducing the passage clearance by about 80 mm; alternatively, prepare an increased counterframe of 100 mm at the design stage.
The system is Push&Go: if the panel is moved manually, it completes the open/close cycle.
The system automatically learns the opening and closing limits of the door and slows down the stroke of the panel before total closing/opening.

Standard equipment allows for push-button opening (either two-position switch or sequential push-button) and automatic closing of the door after 2, 5, or 10 seconds of inactivity.

Photocells, wall or pocket remote controls, and home automation kits for opening from smartphones available.

Kit includes stringers, mullion and pillars for architectural span up to 200 cm (100 + 100) wide and 210 cm high, to be cut to size. Model for finished wall plaster 105 and plasterboard 100.
Finish to be painted.
The jambs are complete with dust brush and black gasket.
Other sizes are available, check feasibility at the company.
Available for glass doors.

he kit includes stringers, mullion and pilasters for architectural span up to 100 cm wide and 210 cm high, to be cut to size. Model for finished wall plaster 105 and plasterboard 100.
The jambs are complete with dust brush and black color gasket.

Other sizes are available, for feasibility contact the company.
Available for glass doors.

Lifty System® is Protek's exclusive patented system that allows for faster adjustment and assembly of the door, completely eliminating the use of hand tools. Screws and fasteners included in the kit.
Maximum capacity 150 kg.
Suitable for wooden doors.
Trolley kit not included.

Variable hardness element, which can be installed inside the rail, allowing the maximum opening of the door panel to be limited.
Can be applied with the counterframe installed, thanks to the pull-out track.

The kit includes a bottom rail made of aluminum to facilitate panel sliding, up to 120 cm in length. Screws for fixing included.
Needs modifications to the lower milling of the panel.

The system allows the door to be completely recessed inside the wall. By pushing with slight pressure, the door is pushed out of the wall so that it can be closed.

Can be applied with the counterframe installed, thanks to the pull-out track.
Not compatible with simultaneous opening kit.
Not compatible with self-closing kit.

Three-module electrical box 40 mm thick. Screws for fixing included.
It is possible to install multiple electrical boxes on the same side of the subframe, one every 10 cm.
